Product Description
Features:
- Starlight, 120dB True WDR, 3DNR
- Max. 4K resolution
- HD/SD switchable
- Audio in interface
- 3.7-11mm moterized lens
- Max. IR length 328ft, Smart IR
- IP67, IK10, DC12V±30%
- Build-in Audio Input
| Model | HAC-HDBW3802EN-ZH-VP-3711 |
| Image Sensor | 1/2" CMOS |
| Effective Pixels | 3840(H)x2160(V), 8MP |
| Scanning System | Progressive |
| Minimum Illumination | 0.005Lux/F1.5, 30IRE, 0Lux IR on |
| IR Distance | 328ft (100m) |
| Lens | 3.7-11mm/F1.5, Motorized lens / Fixed iris |
| FOV-H | 112°~46° |
| Pan/Tilt/Rotation | Pan: 0°~355° / Tilt: 0°~75° / Rotation: 0°~ 355° |
| Resolution | 8MP (3840x2160) |
| Frame Rate | 15fps@4K, 20fps@6M, 25/30fps@4MP |
| Video Output | 1-Channel BNC / CVBS (Can switch) |
| Day/Night | Auto (ICR) / Manual |
| OSD Menu | Multi-language |
| WDR | 120dB True WDR |
| Noise Reduction | 2D/3D |
| White Balance | Auto / Manual |
| Smart IR | Auto / Manual |
| Audio Interface | 1 |
| Power | 12V DC ±30%, Max 7W (12V DC, IR on) |
| Working Temperature | -30°C~+60°C (-22°F~+140°F) |
| Ingress Protection | IP67, IK10 |
